CNC Turret Punching Machine Description Of Main Configuration

The CNC Turret Punching Machine features a robust and stable machine body with an integrated fuselage and a widened design. This structure is achieved through a process of disposable welding, tempering, and forming, all in a single operation. This method ensures the machine's durability and precision.

The machine is equipped with a seamless worktable design that prevents collisions between the plate and the worktable during movement. This design includes dust-proof protection for the guide rail and ball screw, maintaining smooth and clean operation. The seamless worktable enhances the overall efficiency and accuracy of the machine.

Additionally, the CNC Turret Punching Machine includes a folding working table with a side assist platform that uses a cylinder-controlled seamless design, making tooling changes convenient. The turret is made of 40Cr and is processed in a large center, incorporating a German mosaic roulette. The machine also features an automatic clamp function to avoid collisions, ensuring there are no dead areas for punching on the sheet.
