Function and control system of NC hydraulic sheet bending machine

NC hydraulic sheet bending machine one Function:

  1. Slow bending function: you can set the bending speed in order to work, in addition,NC hydraulic sheet bending machine
  2. you can also set the starting slow speed bending position and the waiting time between the work steps (by the numerical control setting or manual setting to choose).
  3. Back-pull bending function: the upper and lower molds clamp the material after the rule back,
  4. so as not to interfere with the rule and the material after the bending.
  5. Arc bending function: just input the distance and the number of steps can automatically convert the arc bending.
  6. Drawing line bending function.
  7. Multiple lower limit, multiple upper limit function: the speed switching point and
  8. the lower dead point stop position is directly controlled by the digital encoder to avoid the redundant empty stroke, which greatly improves the production efficiency.
  9. Handwheel control function: D axis and L axis hand arbitrary control when
  10. the first piece of work piece for trial bending using handwheel adjustment function is greatly convenient to understand the operation and improve the safety.
  11. Control system:
  12. Adopt the new color liquid crystal touch type operation panel, the picture is bright color, touch input programming can be directly input and Angle input programming.
  13. Bending Angle control and post-positioning programming can be set by CNC and fine-tuned by hand wheel.
  14. Can store 100 products, each product 30 steps.
  15. High-speed and high-precision workpiece bending processing using D-axis depth control and L-axis automatic post-positioning control.
