Hydraulic Press Brake Machine factory tutor you how to maintain
Precautions for use of bending machine
1. Before running the bending machine, the tools used must be matched with the control program
2. Be sure to close the bending machine after the end of the work
Two ways to close the bending machine
1. Close the machine to the middle of the bottom dead center, that is, move the slider to the center of the bottom dead center, close the main motor, adjust the operation switch to "0", and the main switch to "0".
2. Close the bending machine with two pieces of wood of the same height, put the two pieces of wood on the workbench, and adjust the button of operation mode to "2". After the bending mechanism is closed, manually pull down the slider until it can reach the block. Then set the operation mode selection button to "0", and finally set the main switch to "0".
Use the emergency stop button
When the emergency stop button is used, all the shafts and pumps stop, but the control system is not shut down. Please restart the machine: first release the emergency stop button, then press the green button to run the machine. No need to reset the upper and lower mode parameters.
Maintenance of bending machine
requirements
1. It is suggested that the staff should have some experience in maintaining and repairing the bending machine, and carefully read the operation manual of the bending machine to be repaired.
2. It is recommended that the bending machine manufacturer overhaul the machine tool
3. The machine operator needs to check the machine every day to avoid oil leakage or loose parts of the machine
4. If you cannot solve the machine fault by yourself, it is recommended to contact the bending machine manufacturer in time
Maintenance of bending machine parts
1. Check the guide rail once a week and remember to oil it
2. The rear stopper also needs oil
3. Check the tightness of the conveyor belt
4. Clean the dashboard and check the driver
5. Clean the mold and check whether it is damaged
Maintenance of hydraulic system
Add hydraulic oil matters needing attention
1. Check the hydraulic oil once a day. When the slider moves to the highest point, observe the position of hydraulic oil, if the hydraulic oil is insufficient, please refueling in time.
2. 10% oil can be added to the hydraulic tank first, so that the hydraulic oil can complete a single cycle, so that not only the volume of the tank can be calculated, but also the circulation frequency of the hydraulic pump.
