1. It is not directly connected with the crank large stamping block, but with relatively small sliding motion and mass level connection,
so that the internal force of inertia force is not as small as the deputy director of rolling conflict CNC turret punch press,
the heat generated by the conflict is relatively small, so as to improve the precision of high-speed mobile CNC turret punch press.
2. The sliding block connected to the main body of the punch (except guide) is done by connecting rod and slider,
kinematic chain is shorter, can tilt the punch and connected to the two auxiliary on the rotation and movement,
and other high-speed punch usually consists of at least three rotation to complete,
so they move to the rotation of the replacement in contrast to the present invention in rigid auxiliary to better.
3. Stamping rather than rolling pairs uses the load of moving the slider horizontally through the slider and the body moving to the bar, and has better rigidity.
4. Through the planning of the mechanism, the crankshaft can reach the position of the next stamping die slider twice a week to complete the double stroke.
This time, the crank slider mechanism will run at half the speed of the original part,
part of the inertia force of the moving part press will be greatly reduced by falling speed, and then balancing will be done more simply.
